Respironics ComfortGel Blue

Description

Key Features:

• Premium blue gel to form effective seal: works together with the thin, form fitting outer silicone membrane to create an effective, self adjusting seal.  Not only does our blue gel provide extra stability, it is thinner and lighter than ever before.
• Premium forehead pad improves comfort and fit: this redesigned forehead cushion reduces pressure points for a more comfortable experience.
• Premium headgear makes fitting and adjusting a snap: Respironics’ one size fits most headgear has EZ Peel tabs and ball-and-socket attachment.  It adjusts easily in four places for a secure, custom fit.
• Silicone comfort flap improves seal: the flap increases comfort, improves mask seal and can be removed for easy cleaning.
• Angled exhalation ports direct air away from your bed partner: the lower profile exhalation port with integrated swivel quietly redirects air flow.
• Stability selector for proper seal and fit: raise and lower the mask to find the right angle, seal and fit for you.

Fitting Guide:

Preparing the mask for fitting:

1. Loosen the straps on the headgear by adjusting the Velcro Tabs
2. Gently squeeze the sides of the Stability Selector and slide the arm upward to set the forehead support arm to its highest position.
3. Disconnect one side of the headgear by releasing one ball-and-socket Quick Clip from the faceplate socket.

Making initial adjustments:

1. Make initial adjustments while sitting .  Place the mask cushion against your face.
2. Pull the headgear over the head.
3. Attach the Quick Clip on the disconnected side.  For easy attachment of the Quick Clip, use the index finger as a guide to find the position of the socket and press the clip into the socket.
4. Adjust both of the upper headgear straps by using the tabs.  Be sure that they are tightened evenly and the forehead pad is lightly touching the forehead.
5. Adjust the bottom headgear straps by using the tabs.  Be sure that they are tightened evenly and the mask is gently sitting on the face. Do not over tighten the headgear.
6. Be sure the headgear straps are parallel and the headgear is fully extended and flat across the back of your head.

Making final adjustments:

1. Connect the air tubing to the swivel elbow and turn on the air.
2. Make final adjustments while lying down.  If the forehead pad does not rest lightly against the forehead, adjust the upper headgear strap.
3. If necessary, adjust the bottom headgear strap so that the masks snug but comfortable against the face. Do not over-tighten the headgear.
4. Check for leaks around the mask while lying down with the air on.

Cleaning tips (outlined by the American Thoracic Society April 2020):

• Daily: clean nasal mask cushion daily with a damp cloth and mild detergent, may use mask wipes
• Weekly: clean full mask system (including headgear) with warm water and mild soap (dish soap). Rinse with water and then air dry away from direct sunlight.

Recommended replacement every 6 months.
